Small Clear Span Tent

A.General Details:

Our small clear span tent is made of aluminum profiles and double coated PVC fabric, we use the hot-dip galvanized steel connectors, and each bay are interchangeable and the bar tensioning system for the covers make our tent safe and stable, with max wind load up to 100-120 km/hour, and snow load up to 1.9kn/㎡; It is a modularized structure which enables short installation period, easy to assembly and disassembly.

Our tent has no poles inside the tent, so inner space can be 100% utilized. It’s the safest and stable structure in the event industry so far, and due to the long-lasting lifespan and flexible combination, more and more businesses or companies choose it as a temporary or semi-permanent shelter for all kinds of outdoor events.

B.Product Materials:

1.Frame material: high-extruded aluminum alloy 6061/T6,?anti-rust surface.

2.Cover material: double PVC-coated fabric, tear-resistance, flame retardant, waterproof.

3.Advantage: Quick Setup, Movable, Safe Structure, 15-20 years lifespan, free installation guidance, free after-sales services, engineer support.

C.Product Specification:

^Span ^Width	^Side ^Height	^Ridge ^Height	^Bay ^Distance	^{Main Profile}
3m	2.6m	3.2m	3m	84x48x3mm
4m	2.6m	3.4m	3m	84x48x3mm
5m	2.6m	3.6m	3m	84x48x3mm
6m	2.6m	3.7m	3m	84x48x3mm
7m	2.6m	3.9m	3m	84x48x3mm
8m	2.6m	4m	3m	84x48x3mm
9m	2.6m	4.3m	3m	84x48x3mm
10m	2.6m	4.4m	3m	84x48x3mm
12m	2.6m	4.8m	3m	84x48x3mm
10m	3m	4.6m	5m	122x68x3mm
12m	3m	5m	5m	122x68x3mm
